- 4.3” Color TFT display with backlit
- Resolution 0.1 μΩ on 2 mΩ range
- Best Measurement Accuracy of +0.03 %
- Mains cum Battery operated.
- High measurement current (10A) for faster settling of measured values on low resistance.
- True 4 wire resistance measuring technique
- Pulse Mode, Auto Hold Operation.
- Bluetooth interface and cloud connectivity through MOT-WARE app
- Inbuilt thermal paper printer
- Low Battery indication to prevent deep discharge of internal recharging battery.
- Temperature Measurement & Correction
| Technical Specifications | |
| Printer Built in Thermal Printer | |
| PC Interface USB | |
| Report Storage: | 1000 Reports |
| Temperature correction | Manual entry or Temperature Probe |
| Temperature Channel: | 1 |
| Dimensions Device: | 368 mm(L) X 283 mm(W) X 188 mm(H) Approx. |
| Weight: | 5.5 Kg Approx. (with Test Lead) |
| Dimensions Wire Fixture: | 1210mm(L) X 210 mm(W) X 150 mm(H) Approx. |
| Weight: | 6 Kg Approx. |
| Environmental | |
| Operating Temperature: | – 0C to 55C |
| Storage Temperature: | – 10C to 60C |
| Relative Humidity : | – 95 % RH at 40C max. (Non Condensing) |
| Power | |
| Mains Power Supply: | 110/230 Volt AC, 50/60Hz |
| Battery Power Supply: | Li-Ion Battery 14.8 V |
| Electrical Specifications | |
| Test Current Injection: | 10A, 1A, 100mA, 10mA, 1mA, 100μA |
| Test ON Alert: | BEEP |
| Safety | |
| Measurement Category: | CAT II (1000V)/CAT III (600V) |
| Reinforced insulation Relevant Standard Specifications: | Safety According to EN 61010-1, EMC According to EN 61326-1 |
